Home > TV Antenna Bundle > HD-2605 Ultra Outdoor TV Antenna with J-Pole Bundle Package

HD-2605 Ultra Outdoor TV Antenna with J-Pole Bundle Package

HD-2605 Ultra Outdoor TV Antenna with J-Pole Bundle Package
Item # Bundle-2605-JPole
Original Price:$157.99
Reviews/Ratings:
Limited Time Offer:$76.95
Accessories
Qty

Rating: 4.97 out of 5.0

Buy this item by 02:00 PM EDT, we will guarantee to ship your item by the same day through UPS Ground. If order is placed on weekend/holiday, item will be shipped on the following business day.
Instant discount with second indoor antenna
Outdoor TV Antenna Pole
LAVA Indoor/Outdoor
HDTV Antenna
Frequently Bought Together:

Amplified Outdoor
HDTV Antenna


PACKAGE Includes:

  • J-Pole *1 (Orig. Price: $38)
  • HD-2605 Outdoor HDTV Antenna Main Unit *1
  • 4 ft. 75Ω RG6 Cable * 1
  • 40 ft. 75Ω RG6 Cable * 1
  • V-frequency Vibrator * 2
  • Main Pole Column * 1
  • Motor-fixed Bolster *1
  • Square Pipe * 1
  • U-frequency Vibrator * 5
  • Black Square Cap * 1
  • M5 Butterfly Screw * 5
  • M4x12mm Screw *4
  • M4x10mm screw * 4
  • M4x18mm screw * 1
  • Central Control Unit Box * 1
  • Remote Control Unit * 1
  • AC Power Adapter * 1

100% Customer satisfaction Similar Model Retail over $120.00 at a major chain retailer!

  • The HD-2605 Ultra with G3 Control Box is our next generation Antenna, it is powerful with built in super low noise amplifier, covers reception ranges up to 150 miles.
  • The HD-2605 Ultra HDTV Antenna equipped with Motor Rotor and new G3 Control Box. You don't need to go out to move the antenna for specified direction any more. Just use the remote control inside your house and you can find the best angel for your TV signal.
  • It is One cable solution for all your TVs at home. You don't need to run addition cable for the rotation control.
  • Dual TV OUTPUT on the control box allows you connect two or more TVs with a splitter.
  • Great for UHF/VHF/FM reception
  • The G3 control box is designed with new technology and adds surge protection and adjustable gain control. Provide more features for the antenna to work at different locations.
  • Surge protection will protect your TV and Antenna from lightning and connection outage on the wire.
  • Adjustable gain control provides you flexibility for signal strength control when your local signal is too strong.

Note: Please connect the antenna directly to your TV sets rather than through the cable outlet at your house, it might have some power issues if you connect it through your cable outlet.

Outdoor HDTV Antenna20% MORE GAIN

This is the most powerful outdoor HDTV antenna that we carry. By looking at the VHF and UHF gain, you can see how much power the outdoor HDTV antenna has.

HD-2605 Ultra is a much stronger outdoor HDTV antenna unit. Best for those who really need more gain from your location. For some reasons, it might affect picking up signals which is not too far from user's location. So if most of the broadcasting towers are within 40 miles, usually we would recommend our indoor HDTV antennas (i.e. BA700, HD600, etc.) or outdoor HDTV antennas(HD-2805).
Also due to various restrictions, we cannot guarantee that which channels the outdoor HDTV antenna must pick up.

There are too many external factors that can affect our TV antenna picking up signals. Not talking about those existed factors (i.e. trees, area/distance, buildings, weather, airport, etc.), we still have chances to improve the performance ourselves by installing our TV antenna a bit higher (more than 30 to 50 feet above ground level) to reduce the interference from them. This step might give you chances to improve some tv channels reception. (Color change from blue/violet color to red color or even better result)

Outdoor HDTV Antenna IDEAL DISTANCE: 40 to 80 miles

For best result, this outdoor HDTV antenna are ideal for living 40 to 80 miles away from broadcasting towers. People who live in the city like in L.A. and are close to broadcast towers should get indoor HDTV antennas. This outdoor HDTV antenna is ideal for people who are about 40 to 80 miles away even though it can work for up to 150 miles without mountain, trees , weather or other external restrictions.

For more accurate result, please input full address at our Easy TV Antenna Reception Map by antennaweb

Installation Instruction download:
* How to connect your LAVA Outdoor Antenna
* User Manual and Install Instructions



Product Dimension: 22 inch x 30 inch x 4 inch

Note: Due to various restrictions, we cannot guarantee customers which channels they can pick up. Customer should be responsible to those reception issue. If customers are not satisfied with outdoor HDTV antenna's reception, you can return the item you order. And shipping fee is non-refundable. Customers should be responsible to all return shipping cost

Easy Installation

  1. Assemble the outdoor HDTV antenna as diagrams instructed from A to H
  2. Use ? iron pipe to install the outdoor HDTV antenna. For best reception, put the outdoor HDTV antenna at the highest point of your roof or at a space that has clear open view.
  3. Connect the outdoor HDTV Antenna using the included RG6 cable to the central control unit. ANT IN port. The control signal will go through the cable to rotate the outdoor HDTV antenna.
  4. Connect the control unit TV OUT to your TV RF input.
  5. Connect the power adapter.
  6. Scan Channels from your TV menu.
  7. Start to use the outdoor HDTV antenna and enjoy the HDTV program.

For best result, the distance between the control unit box and your TV set should be within 20 ft. And the distance between the outdoor HDTV antenna and the control unit box should be within 50 ft.





Frequently Asked Questions MORE FAQs about our Indoor/Outdoor HDTV Antenna

YES! - The outdoor HDTV antenna works on any standard TV or HDTV. You can use your analog TVs with a DTV converter box and at the same time have the access to digital TV broadcasts.
YES! - HDTV broadcasts quality is often superior to the quality of the same HD programs received through a paid satellite subscription. Not only the quality is better, OTA HDTV is free of charge. To pick up HD signals you will need a HD antenna.
YES! - HD antennas are much easier on the budget. Take a look at our ourdoor HDTV Antenna selection.
YES! - Over 90% of HDTV broadcasts are on the UHF band. Unless there are HDTV broadcasts on the VHF band in your area, don't bother with VHF
antennas. These outdoor antennas are typically of much bigger size, more expensive and more difficult to install. In principle, you can buy a VHF/UHF antenna to cover both bands
YES! - If you want to pick up signals coming from different directions you need either two outdoor directional antennas or an antenna rotator.
If you have any other questions. Send us an email.

No power on the control box?
If there is no power on the control box, it may be problem on the Power adapter or the control box. You can test the power adapter to see if the adapter is OK or not first. If your adapter is still work, then the problem should be with the control box. If your adapter does not have any output, then the adapter may be defective. You can contact us to replace the defective part under the Warranty period.

Remote no light up?
If your remote control does not light up when you press the button, open the batteries holder to check the batteries. Replace the batteries to try again. If you change to new batteries and the remote still not light up, the remote may be defective and need to be replaced.

The Outdoor HDTV Antenna can't rotate itself?
This Outdoor HDTV Antenna is designed with rotor motor inside. The Rotor is controlled by the signal from the control box inside your house. If you install the HDTV Antenna and can get signal but can not rotate the HDTV Antenna itself, you need to test the rotate button on the control box.
Tap your finger on the rotation button on the control box, if the green light flash on, then the control box should work OK and control your Outdoor HDTV Antenna, check the connection wire make sure that all the cables are connect correctly.
If you tap your finger on the Rotation button and the green light not on, it means the control rotation circuit has problem with the box. You need to contact us for replace of the control box.
If your control box can control the rotation but the remote can not. Check the problem 2 to see if your remote light up normal first. If your remote light up when you press the button but the Control box did not response, then may be the remote or the control box has problem. You can contact us to replace the remote first.

Can not find the RED CAP from the package?
The red cap was replaced by the built-in black one, and it can be found at the one end of the square pipe.



Specification:

Frequency(VHF) 40 - 300MHz
Frequency(UHF) 400 - 860MHz
Gain(VHF) 28 - 32 dB
Gain(UHF) 32 - 36 dB
Power 3W
Max. Rotation 360˚
Impedance 75Ω
Max. Output Level 145 dB�V
Working Voltage 110V/60Hz
AC Output 15-19V




We will recommend you to do a test by yourself using the cable we extra offer before you install the antenna outside of the building.

1. If you plug the AC Adapter and connect to the control unit box, you should first see a red light is on on your control unit box.
Outdoor HDTV Antenna
2. Once you connect the control unit box(a port on the box named ANT) to your antenna with a cable, now you should see the red light is on on your antenna. If not, you can test again with different cable to see if the problem is caused from the cable.
Outdoor HDTV Antenna
Outdoor HDTV Antenna
3. After making sure both red light are on, everytime when you press the button on the control unit box, you can see a green light is on on the control unit box and your antenna should be rotating.
Outdoor HDTV Antenna
Above is a self-test instruction. Basically, you can test to see if your antenna set works without connecting the antenna to your TV set unless you're testing if any signals picked up by the antenna.
After you assemble all the parts correctly, the antenna should rotate about 360 degree and stop then rotate reversely by pressing the button on the unit box. Or you can change the direction by double clicking the button.
If your HDTV antenna didn't rotate, you can find out the problem easily from the steps above.

When you contact us asking for technical support, we appreciate if you can include a little details about which step above the error shows, so that we can more accurately diagnose the factor of problem your HDTV antenna might have.

For best result, the distance between the control unit box and your TV set should be within 20 ft. And the distance between the outdoor HDTV antenna and the control unit box should be within 50 ft.
